TCK63-3000
The TCK63 – 3000 is an advanced CNC slant lathe meticulously engineered to meet the diverse and exacting demands of modern manufacturing. Its slant – bed design not only offers enhanced stability during high – speed operations but also enables efficient chip evacuation.
- High – Torque Spindle for Heavy – Duty Machining Operations
- Ultra – Precise Control System Ensuring Micron – Level Accuracy
- 3000mm Extended Bed for Long – Shaft and Large – Scale Workpiece Machining
HANDEMO
Parameters
| Product model | TCK63-3000 | Control system | KND |
|---|---|---|---|
| Maximum rotation diameter on the bed | 720mm | Tailstock sleeve taper | Mohs 6# |
| Maximum cutting length | 3000mm | Standard tool holder type | horizontal 12-station servo |
| Maximum cutting diameter | 500mm | External circular tool size | 32×32mm |
| Standard cutting diameter | 380mm | Boring bar diameter | φ50/φ40/φ32/φ25/φ20mm |
| Maximum rotation diameter on the slide | 420mm | End tool holder | 32×32mm |
| Spindle end face type and code | A2-11 | Can I choose a tool nearby | Yes |
| Spindle aperture | 104mm | Maximum load-bearing capacity of disc parts | 450 (including accessories such as chucks) |
| Maximum bar diameter | 90mm | Maximum load-bearing capacity of shaft parts | 1000 (including accessories such as chucks) |
| Spindle speed range | 50~2000 r/min | Machine dimensions (length * width * height) | 5850×2030×2375mm |
| Spindle maximum output torque | 354Nm | Machine weight | 12000 kg |
| Main motor output power (30 minutes/continuous) |
18.5/22KW | Processing accuracy | IT7 |
| Chuck diameter | 10 inches (optional 12) | Workpiece roundness | 0.0025mm/Ф75 |
| Chuck type | hollow chuck | Workpiece cylindricity | 0.010mm / 150mm |
| X-axis fast moving speed | 12 m/min | Workpiece flatness | 0.010mm/Ф200mm |
| Z-axis fast moving speed | 16 m/min | Workpiece surface roughness | Ra1.25μm |
| X-axis travel | 300 mm | X-axis positioning accuracy | 0.008mm |
| Z-axis travel | 3050 mm | Z-axis positioning accuracy | 0.008mm |
| Tailstock stroke | 2800mm | X-axis repeat positioning accuracy | 0.004mm |
| Tailstock sleeve stroke | 100mm | Z-axis repeat positioning accuracy | 0.004mm |
HANDEMO
Features
High - Torque Spindle
Equipped with a cutting – edge high – torque spindle, the TCK63 – 3000 can deliver up to 354 Nm of torque. This enables it to effortlessly handle heavy – duty cutting operations on tough materials such as stainless steel, alloy steel, and titanium.
Ultra - Precise Control System
Our advanced control system, integrated with high – resolution encoders and advanced motion control algorithms, guarantees micron – level precision. The TCK63 – 3000 can achieve positioning accuracy of ±0.008 mm and repeatability accuracy of ±0.004 mm.
3000mm Extended Bed
Featuring an extended bed length of 3000mm, the TCK63 – 3000 is specifically engineered for long – shaft and large – scale workpiece machining. The extra – long bed provides stable support for workpieces of various lengths and diameters, allowing for the seamless machining of components such as wind turbine shafts, large – diameter pipes, and industrial machinery parts.
Intuitive Operation Interface
The user – friendly control panel of the TCK63 – 3000 is equipped with a large – screen touch display, making programming and operation a breeze. Operators can easily input machining parameters, monitor the machining process in real – time through live video feeds and graphical simulations, and make on – the – fly adjustments as needed.
HANDEMO
Application Areas
- 24/7 online reception service
- On-site installation
- 5-year warranty
